Picture of TORRENT: Solid Fuel Boilers

TORRENT: Solid Fuel Boilers

Low cost heating and high efficienct

TORRENT Solid Fuel Boilers are suitable for biomass use. High quality manufacturing and smart design offer maximum efficiency as well easy operation and maintenance. The TORRENT solid fuel boiler series includes wood-coal boilers, cast iron and steel boilers, as well as boilers with silo for pellets, shells, core, etc.

TORRENT Phoenix 3 into 1

The Torrent 3 in 1 Phoenix Steel Boiler is suitable for combustion of:

Ο Χαλύβδινος Λέβητας Torrent Phoenix, 3 σε 1 είναι κατάλληλος για καύση:

1. Solid fuels in the form of granular materials for automatic feeding through a screw-feeder

2. Solid fuels such as coal and wood for manual feeding via a special built-in grill

3. Oil fuel with burner

Regardless of the fuel choice, configuration is done using the control panel, which features a series of functions for complete boiler control

TORREN PHOENIX FRONT

Benefits

  • Suitable for the combustion of pellets / biomass, wood and oil
  • User-friendly operation menu with easy adjustment system and constant parameter control
  • Simple burner maintenance
  • Absolute protection against fire return to the silo through non-return valve, located between silo and screw (safety dosing)
  • Upgraded constant motor working protection with integrated clamp meter on control panel
  • Constant boiler protection against overheating
  • Modern cylindrical boiler design
  • Automatic adjustment of air supply from the fan
  • Silo can be placed on the right or left of the boiler
  • Easy flame checking through a hole
  • Nuclear burner support on adjustable clamp
  • Secure door closing
  • Made entirely in Greece

Technical Information

Output range: from 35.0 to 116 kW

Max. working pressure: 3 bar

Warranty: 5 years

TORRENT Leo

The Torrent Leo Steel Boiler is manufactured entirely in Greece and is intended for solid fuel combustion supplied manually such as wood and charcoal, for hot water up to + 90°C (3 levels available). The TORRENT Leo boiler operates with accelerated air circulation through the blower located on the lower level. The fan (on / off) and its speed is controlled by the control panel.

TORREN LEO

Benefits

  • Robust manufacturing
  • Fuel supply placed on special grille made of high-strength cast iron
  • User-friendly
  • Simple cleaning and maintenance procedures thanks to the ergonomic external cleaning lever
  • High performance
  • Possibility to convert into a solid biomass boiler for automatic supply (TORRENT Phoenix)
  • Suitable for oil burning featuring burner adjustment and a corresponding control panel
  • Made 100% in Greece

Technical Information

Power range from 35.0 to 116.5 kW

Maximum operating pressure 3 bar

Warranty: 5 years

The flue gas turbines included in the unit result in a reduction of the flue gas temperature and thus, to an increased efficiency

The temperature is controlled by adjusting the fan hydrostat

The pump hydrostat activates the pump when the water temperature exceeds the selected temperature

The safety hydrostat cuts off the power when temperature exceeds +95°C

TORRENT Draco

TORRENT Cast Iron Boiler is made of high-quality cast iron. Thanks to its compact shape is the ideal heating solution for domestic use as well as for small buildings.

Its design ensures various solid fuel combustion, such as coke, wood and charcoal. Τhe large door opening in the combustion chamber facilitates the use of large wood up to 220mm.

It is user-friendly, and it can be installed in heating systems with natural or forced water circulation. Available with two front doors for comfortable supply and maintenance. It can also be converted into an oil or gas boiler without time-consuming procedures by adding a suitable burner.

TORRENT DRACO

Benefits

  • Robust manufacturing made of high-strength cast iron against corrosion
  • High pressure resistance (up to 4bar)
  • Easy use and maintenance
  • Compact size
  • Cost-efficient operation
  • Excellent value for money

Technical information

Power range from 30.0 to 49 kW

Max. operating pressure: 4 bar

Warranty: 3 years

Downloads

Brochures
For more information regarding Pricelists, Technical Data, Manuals & Warranties, please click here.
