VASEN: PP-R Type III Pipes & Fittings

VASEN Research and Development has been able to come up with advanced PP-R Type III piping systems. All the products have the benefit of decades of experience and the latest technology, ensuring ease of installation, safety, and a longer life. Choosing VASEN means uncompromising quality for every project – from residential installations to large-scale technical and industrial applications.

Why Choose VASEN:

  • 1. 6 fully automated state-of-the-art manufacturing plants
  • 2. Latest-generation machinery using German technology
  • 3. More than 120 international quality certifications
  • 4. Product tested across 5 continents and in more than 30 countries
  • 5. Annual global turnover: USD 2 billion

The full VASEN range comprises pipes and fittings up to Ø 315 mm, available as socket fusion, threaded, electrofusion, and butt-weld systems, including all installation tools needed.

Advantages

  • Fast and easy fusion welding. Reduces installation time.
  • Fully sealed connections
  • Low thermal expansion for dimensional stability
  • Smooth internal surface with no scaling or pressure loss
  • High corrosion resistance
  • High Mechanical Strength under Impact and Internal Pressure
  • Hygienic water supply: Anti-bacterial protection
  • Lightweight, to facilitate handling and installation
  • Low levels of noise and pressure loss
  • Can withstand chemical attacks, such as acids, salts, and alkalis
  • Non-toxic, safe for drinking water, eco-friendly
  • Environmentally friendly - 100% recyclable material
  • There shall be no emission of harmful substances during fire.
  • Service life up to 50 years
  • 10-year written warranty

Classic Series

Made from random polypropylene copolymer (PP-R), with strong resistance to both heat and corrosion.

Continuous Process of Extrusion to Achieve Consistency of Quality

PN value 20, with max. permissible operating pressure of 20 bar

Straight pipe lengths of 4 meters

SDR 6 for superior strength and reliability

Diameters range: Ø 16 to Ø 160

UV Protection Series

Fiberglass-reinforced polypropylene pipes with protection against ultraviolet rays, intended for installations with both hot and cold water.

Straight pipe lengths of 4 meters

UV Protection Layer prevents degradation under UV exposure

SDR 7.4, heavy-duty, reinforced wall for demanding water systems

Diameters: from Ø 20 through Ø 63

Clima Series

Designed for heating, cooling, air conditioning, compressed air, and specialized fluid services, offering high levels of reliability in difficult applications.

Straight pipe lengths, each measuring 4 meters

Fiberglass reinforced for increased strength

Compressed linear expansion and improved thermal stability

SDR 11 thick wall for pressure resistance

Blue identification mark: A special mark on the product for easy identification

Diameters ranging from Ø 25 to Ø 160

Fiberglass Reinforced Series

Three-layer PP-R Fiber Composite Pipe, symbolizing the "Generation Next" of piping systems.

Linear Expansion reduced to 30% of Standard PP-R

High mechanical strength & pressure-resistance

SDR: 7.4 for maximum dimensional stability

High impact strength even at low temperatures

Trustworthy socket fusion joints with PP-R fittings

Convenient for water supply, central heating schemes, HVAC projects, solar schemes

Straight pipe lengths of 4 meters

Diameter Range: Ø 20 to Ø 160

Fusion Fittings

Socket Fusion PP-R Fitting: For smooth, hygienic, and secure connections to water services

Threaded PP-R Fittings: Blend fusion power with threaded convenience

Precision fusion welding of monolithic leakage-free joints

High resistance to temperature and pressure

Hygienic and safe for drinking water and technical fluids

Applicable in heating, HVAC, hot water and industrial use

Diameters ranging from Ø 20 to Ø 63

Electrofusion Fittings

Leak-tight and permanent joints by electrofusion

Installation that's quick and hassle-free.

High resistance to pressure and temperature

Suitable for drinking water & High Purity fluids

Durable, resilient

Compatible with all PP-R systems

Diameters ranging from Ø 63 to Ø 160

Welding Times

For proper and accurate installation of VASEN PP-R pipes and fittings, it is imperative to follow prescribed times of heating and welding. Correct fusion will assure a compact joint with high mechanical strength.

Required Preheating Time
Diameter Ø (mm)Heating Time (sec)
16 5
20 5
25 7
32 8
40 12
50 18
63 24
75 30
90 40
110 50

Required Welding Time
Diameter Ø (mm)Welding Holding Time (sec)Cooling Time (min)
16 4 2
20.25 4 3
32 4 4
40 6 4
50 6 5
63 6 6
75.90 10 8
110 15 10

Applications


Εφαρμογές Θέρμανσης Heating systems
Εφαρμογές Ύδρευσης Water supply systems
Εφαρμογές Κλιματισμού Air Conditioning
Εφαρμογές Ψύξης Cooling
Εφαρμογές Ενδοδαπέδιας Θέρμανσης Underfloor heating
Εφαρμογές Βιομηχανικων Δικτύων Industrial applications
Πόσιμο Νερό Drinking water installations
