Conex|Bänninger Fittings

110 Years of Innovation

Since 1909, IBP (International Building Products) - Conex | Bänninger specialises in designing and manufacturing innovative, certified fittings, with special molds, thus providing a wide range of products: copper, bronze & brass (DZR), welded, pressed & compression fittings, suitable for water supply, drinking water, natural gas, heating, cooling and air conditioning systems, providing an excellent choice for industrial and urban installations.

Bänninger Copper Fittings

The Bänninger fitting production process is fully vertical using primary copper (casting in the form of ingots, "turtles") with a content of 99.99%, according to DIN EN 1254-1, DIN EN 1254-5, DVGW GW6, DVGW GW8. This method makes Bänninger copper fittings stand out for their durability & quality, as they are the only ones certified for medical gas networks, since they are arsenic free.

They are available in a full range of shapes and dimensions from 6 to 159mm. Suitable for copper pipe connections.

Benefits

  • Suitable for drinking water systems as per DIN 50930-6
  • Absolute dimensional accuracy
  • High temperature tolerance
  • Unlimited lifespan
  • Absolute safety under high pressures
  • Corrossion resistant
  • Full and compete fittings range

Applications

Plumbing & Water Supply Systems
Πόσιμο Νερό Drinking Water Systems
Heating
Natural Gas
Cooling
Ιατρικά Αέρια Medical Gas

Bänninger Solder & Threaded Bronze Fittings

Having a high copper content (85% Cu), the Bänninger brass fittings are the bet suitable choice for copper networks, as due to the homogeneity of the installation, the risk of electrolysis is prevented. Composition is completed with 5% lead, 5% zinc and 5% tin

They also provide complete sealing thanks to their cylindrical threads according to ISO 7-1 and BS EN 10226-1 (DIN 2999).

Moreover, due to their composition (85% Cu), Bänninger brass fittings are suitable for natural gas networks as thread deformation at high temperatures developing during hard welding (650 - 800 ° C) is prevented.

A wide range of fittings and dimensions from Ø8 (1/4 ”) to Ø64 (2 1/2”) is available, featuring stable alloy content and special thread turning treatment according to DIN 2950, EN 10242 and DVGW GW6.

Advantages

  • Suitable for drinking water systems as per DIN 50930-6
  • Unlimited lifespan
  • Conic thread for secure connection
  • Highly corrossion resistant
  • Resistance to overheated welding
  • Indestructible in turbulent flow
  • Flawless finish inside and out
  • Guaranteed & certified without restrictions

Applications

Plumbing & Water Supply Systems
Drinking Water Systems
Θαλασσινό Νερό Seawater
Εφαρμογές Άρδευσης Irrigation
Heating
Natural Gas
Εφαρμογές Κλιματισμού Air Conditioning
Cooling
Βιομηχανικά Αέρια Industrial Gas
Εφαρμογές Πετρελαίου Liquid Fuels

Conex | Bänninger Compression Fittings

The full range of Conex | Bänninger compression fittings offers fast and secure piping of every category. Quick and simple, the connection process provides great working time saving and safe system operation.

Suitable for Copper, Steel, Stainless Steel and Plastic Pipe connections.

The compression fittings range features more than 60 forms for pipe sections from Ø6mm to Ø54mm.

Benefits

  • They are made entirely of primary DZR brass alloy
  • They are manufactured according to EN1252-2 and threads as per EN1254-4
  • Suitable for installations where no case of fire transmission is allowed
  • No need to use teflon tape
  • Certified by EN 1057

Applications

Plumbing & Water Supply Systems
Drinking Water Systems
Heating
Natural Gas
Cooling

Bänninger >B< Press Copper & Bronze Fittings for Heating and Water Systems

The Conex Bänninger superiority in the field of welded copper - bronze fitting is complemented by the smart range of pressed Bänninger> B < Press. These fittings can provide a solution to any installation, having all the corresponding certificates for the intended use.

Three-point pressing: The O-ring has two antidiameter notches, in case the component is not pressed correctly, even with very small network pressure. Upon checking by a technician, it can detect a leak, for direct pressing and sealing.

A complete series with the appropriate fitting is available for each application. Comes in a full range of shapes and dimensions from Ø12mm to Ø108mm.

Benefits

  • Properly shaped rubber for fast visual leakage control if not pressed
  • High quality O-ring which ensures secure connection during pressing
  • Fast and safe installation
  • Suitable to use with all types of copper pipe (hard, semi-hard, soft)
  • Designed for up to 16 bar pressure
  • Temparature range from -35°C to +110°C
  • Tested to pressures up to 64 bar
  • Dedigned and manufactured according to BS 8537 standard. They also bear international WRAS, KIWA and DVGW certifications

Bänninger >B< Press GAS Copper & Bronze Fittings

Bänninger >B< Press GAS Copper & Bronze Fittings are user friendly and very quick to install, leading to savings on labour costs. They also offer the advantage of a flame free installation, therefore posing no fire risk.

They are suitable for any type of copper pipe connections, hard, semi-hard, soft, in gas and LPG networks.

Available in a complete range accompanied by the appropriate fitting. They come in a full range of shapes and dimensions from Ø15mm to Ø54mm.

Benefits

  • They feature a yellow O-ring made of H-NBR rubber that can withstand + 650°C for 30 min
  • They have a yellow mark on the outside to be recognizable even after pressing
  • Fast and safe installation
  • Designed for up to 5 bar pressure
  • Temparature range from -20°C to +70°C
  • Designed and manufactured according to BS 8537_2010 standard. They also bear international WRAS, KIWA and DVGW certifications
  • Tested by DVGW G5614

Applications

Plumbing & Water Supply Systems
Drinking Water Systems
Heating
Natural Gas
Cooling

Bänninger >B< ACR Fittings for Cooling Installations

The Conex Bänninger wide range includes fittings for refrigeration and air conditioning systems.

The Bänninger> B

Benefits

  • Operation pressure up tp 45 bar
  • Certified to ASME/ANSI B16.22
  • Made from primary copper (turtle) with a content of 99.99% according to DIN EN 1254-1, DIN EN 1254-5, DVGW GW6, DVGW GW8

Applications

Πόσιμο Νερό Drinking Water Systems
Heating
Εφαρμογές Κλιματισμού Air Conditioning
Cooling

Bänninger K65 ACR Components for Cooling Installations

The Bänninger K65 is the Conex/Bänninger new series of ACR fittings for high pressure applications. These fittings are used especially in cooling systems, mainly in Supermarkets, where the trend is to use even more eco products.

Bänninger K65 fittings are ideal for high pressure piping systems, using Carbon Dioxide (CO2) as a refrigerant

The Bänninger K65 series is available from 3/8 "to 2 1/8".

Benefits

  • Operation pressure up to 120 bar
  • Made from primary copper (turtle) with a content of 99.99% according to DIN EN 1254-1, DIN EN 1254-5, DVGW GW6, DVGW GW8
  • Special green sign on the outside for instant recognistion

Applications

Πόσιμο Νερό Drinking Water Systems
Heating
Εφαρμογές Κλιματισμού Air Conditioning
Cooling

Downloads

Brochures
For more information regarding Pricelists, Technical Data, Manuals & Warranties, please click here.
